Product Description
- Backlit LCD display with maximum readings of 9999.
- Large display for simultaneous reading of the 4 channels.
- Resolution: 0.1º C / 0.1º F, 1º C / 1º F.
- Measuring ranges: K/J/T/E/R/S/N Types.
- Overload indication.
- Low-battery indication.
- Auto power off with disable function.
- Sampling rate : 1 time/secUSB Data Transfer Output & Software.
- Software Included (Windows® 2000, XP, VISTA, 7 Compatible)
- 9999 per each Channel Records Data Logger.
CALL-Fit to quick read memory data.(50 page/sec)
|
Thermocouple range |
K Type : -100°C ~ 1300°C ( -148°F ~ 2372°F ) |
|
Accuracy (18°C ~ 28°C ambient) |
|
|
Operation temperature and humidity |
0°C~50°C (32°F~122°F), 0~80%RH |
|
Operation temperature and humidity |
-20°C ~ 60°C (-4°F ~ 140°F), 0~80% RH |
|
Power requirement |
Size AAA / 1.5V1UM-4 x 4pcs |
|
Input protection at thermocouple input |
24V AC/DC Maximum |
|
Dimension (Includes housing) |
184mm (L) x 82mm (W) x 44mm (H) |
|
Weight (Includes housing, batteries) |
Approx. 450g |
|
Battery AAA/1.5V/UM-4 x 4 pcs |
|
