Battery Types Tested
|
Compact storage batteries, Alkali and lead-acid batteries..
|
Battery Capacity
|
0 to 500AH
|
Resistance
|
Ranges : 40mΩ, 400mΩ, 4Ω, 40Ω Resolution : 10μΩ, 100μΩ, 1mΩ, 10mΩ Accuracy : ±(1%reading + 8digits) on all ranges.
|
Measurement
|
Current : 25mA, 2.5mA, 250μA,25μA Frequency : 1KHz Accuracy : ±10%
|
Voltage
|
Measurement : 4V, 40V Resolution : 1mV, 10mV Accuracy : ±(0.1%rdg ±6digits)
|
Open Circuit Voltage
|
3.5Vpp max
|
Data Memory
|
500 data sets
|
Continuous Data Memory
|
9600 data sets (only use PC download)
|
Comparator
|
Setting : Resistance upper and lower limits and voltage throughold limit. Memory : 99 sets of values
|
Operating Environment
|
0℃ to 50℃ (32℉ to 122℉), 80%RH or less, non-condensing.
|
Maximum Input Voltage
|
50VDC
|
Power Supply or AC Adapter
|
Six size AAA 1.5V
|
Battery Life
|
7 hours
|
Weight
|
Approx. 500g including batteries
|
Dimensions
|
Approx. 250(L)×100(W)×45(H)mm
|
Accessories
|
Instruction manual, Batteries, Test probe, Software, RS232 cable.
|
Optional Accessories
|
AC adaptor (Isolated output 9VDC)
|
